VMAX MR86-50 Group 21R AGM Deep Cycle Marine Battery – 50Ah / 360 CCA

VMAX

Was: $159.99
Now: $149.99
SKU:
MR86-50
Shipping:
Free Shipping
Voltage:
12V
Type:
AGM
Capacity:
50Ah
Group Size:
21R
Terminals:
M6 Inserts
Polarity:
- Left / + Right
Deep Cycle:
Yes
Length:
7.5" - 7.9"
Width:
6.5" - 6.9"
Height:
6.5" - 6.9"
Weight:
32 lbs
Capacity Group:
40 - 50Ah
Capacity Group:
50 - 100Ah
In Stock
Adding to cart… The item has been added

Product Description

50Ah Marine Deep-Cycle Battery

The VMAX MR86-50 12V deep cycle marine battery delivers true AGM performance with a 50Ah capacity in a compact Group 21R case. It’s built for applications that need strong, steady power for extended periods.

Engineered using VMAX’s military-grade AGM construction, the MR86-50 features thick internal plates, tightly packed separators, and a sealed, maintenance-free design. The result is excellent vibration resistance, high output, and durability that holds up in the toughest environments.

Features & Benefits

  • 50Ah Deep-Cycle Capacity – Designed for frequent deep discharges without loss of capacity.
  • High Output – 450 cranking amps ensure reliable power in all weather conditions.
  • AGM Construction – Heavy-duty plates with Absorbed Glass Mat separators for extreme durability.
  • Heavy Vibration Resistance – Rugged construction ideal for marine, RV, and industrial environments.
  • Group 21R – Direct-fit replacement for numerous marine, RV, and off-grid applications.
  • Low Self-Discharge – Maintains a charge longer between uses than conventional flooded batteries.
  • Temperature Tolerant – Dependable starting power in both high and low temperatures.
  • M8 Insert Terminals – Includes new hardware for quick installation and secure connections.
  • Left-Positive Polarity – Verify your current battery's terminal locations before purchase.
  • Built for Commercial Use – VMAX takes pride in building Tough Batteries for Tough Applications.

VMAX Marine Series AGM

VMAX Marine deep cycle batteries are engineered for applications that demand consistent power and zero excuses. Built with thick, military-grade lead plates and tightly compressed AGM separators, they deliver true deep-cycle endurance, fast recovery, and consistent output—day after day.

These batteries are purpose-built for tough environments – from marine electronics & trolling motors, to house power banks. You get rugged construction, long runtime, and maintenance-free reliability in a single platform that handles long power draws and sustained cycling. When failure isn’t an option and compromises cost you, VMAX Marine AGM is built to perform.

Specifications

MR86-50

VMAX MR86-50 Specifications

12 Volt Group 21R AGM Deep Cycle Marine Battery

  • Nominal Voltage 12V
  • Capacity 50Ah
  • Group Size 21R
  • Type Deep-Cycle AGM
View additional specificationsHide additional specifications
Electrical
Nominal Voltage 12 Volts
Capacity 50Ah
Type Deep-Cycle AGM
Cold
Cranking Amps
360 Amps
Marine
Cranking Amps
1150 Amps
Dimensions & Fitment
Group Size 21R
Length 7.80" (198 mm)
Width 6.60" (168 mm)
Height 6.70" (170 mm)
w/terminals
Terminals M6 Inserts
(hardware included)
Polarity - Left / + Right
Weight 32 lbs (14.5 kg)
Charging & Warranty
Charging Current 3 - 15 Amps
Charging Voltage 14.4V - 14.9V
Float Voltage 13.5V - 13.8V
Warranty 1 Year

Charging Note: Use a 12V AGM-compatible charger at 14.4V–14.9V (float 13.5V–13.8V). Do not use flooded-battery charge profiles on this battery.

MR86-50 Datasheet
Cross-Reference

VMAX MR86-50 Battery Cross-Reference

View DetailsHide Details

Group 21R Batteries: 8G40C, BW12500, CB12500-IT, CT1250, DURA12-44C/FR, DURDC12-40C, ES40-12, ES40-12E, ES50-12, M40-12 SLD M, M50-12 SLD M, MB86-50, MR86-50, NPG12-40Ah, PC1200, PC1200MJT, PS-12450 M6 VDS, PWL12V38, SCP12500 M6, SG12400RT, SLAA12-44C/FR, SLADC12-40C, SLR50.

Important: Always confirm your battery's dimensions, terminal configuration, and specifications before purchase to ensure proper fit and performance.
