Product Description
50Ah AGM Deep-Cycle Mobility Battery
The VMAX MB86-50 12V deep cycle battery delivers AGM performance with 60Ah of capacity in a compact Group 21R case. It’s built for mobility, medical and commercial applications that need strong, steady power for extended periods. Engineered using VMAX’s military-grade AGM construction, the MB86-50 features thick internal plates, tightly packed separators, and a sealed, maintenance-free design. The result is excellent vibration resistance, high output, and durability that holds up in the toughest environments.
Features & Benefits
- 50Ah Deep-Cycle Capacity – Designed for frequent deep discharges without loss of capacity.
- AGM Construction – Heavy-duty plates with Absorbed Glass Mat separators for extreme durability.
- Heavy Vibration Resistance – Rugged construction ideal for marine, RV, and industrial environments.
- Group 21R – Direct-fit replacement for wide range of mobility and commercial equipment applications.
- Low Self-Discharge – Maintains a charge longer between uses than conventional flooded batteries.
- Temperature Tolerant – Dependable starting power in both high and low temperatures.
- M6 Insert Terminals – Includes new hardware for quick installation and secure connections.
- Left-Negative Polarity – Verify your current battery's terminal locations before purchase.
- Built for Commercial Use – VMAX takes pride in building Tough Batteries for Tough Applications.
VMAX Mobility Series AGM
VMAX MB Series deep cycle batteries are engineered for applications that demand consistent power and zero excuses. Built with thick, military-grade lead plates and tightly compressed AGM separators, they deliver true deep-cycle endurance, fast recovery, and consistent output—day after day. These batteries are purpose-built for tough environments – from power wheelchairs & mobility scooters, to medical equipment & commercial electronics. You get rugged construction, long runtime, and maintenance-free reliability in a single platform that handles long power draws and sustained cycling.
MB86-50
VMAX MB86-50 Specifications
12 Volt Group 21R Deep Cycle AGM Battery
- Nominal Voltage 12V
- Capacity 50Ah
- Group Size 21R
- Type Deep-Cycle AGM
| Electrical | |
|---|---|
| Nominal Voltage | 12 Volts |
| Capacity | 50Ah |
| Type | Deep-Cycle AGM |
| Cold Cranking Amps |
360 Amps |
| Marine Cranking Amps |
1150 Amps |
| Dimensions & Fitment | |
| Group Size | 21R |
| Length | 7.80" (198 mm) |
| Width | 6.60" (168 mm) |
| Height | 6.70" (170 mm) w/terminals |
| Terminals | M6 Inserts (hardware included) |
| Polarity | - Left / + Right |
| Weight | 32 lbs (14.5 kg) |
| Charging & Warranty | |
| Charging Current | 3 - 15 Amps |
| Charging Voltage | 14.4V - 14.9V |
| Float Voltage | 13.5V - 13.8V |
| Warranty | 1 Year |
Charging Note: Use a 12V AGM-compatible charger at 14.4V–14.9V (float 13.5V–13.8V). Do not use flooded-battery charge profiles on this battery.
MB86-50 DatasheetVMAX MB86-50 Battery Cross-Reference
View DetailsHide DetailsReplaces these 12V 40-50Ah Batteries with Insert Terminals: 8G40C, BW12500, CB12500-IT, CT1250, DURA12-44C/FR, DURDC12-40C, ES40-12, ES40-12E, ES50-12, M40-12 SLD M, M50-12 SLD M, MB86-50, MR86-50, NPG12-40Ah, PC1200, PC1200MJT, PS-12450 M6 VDS, PWL12V38, SCP12500 M6, SG12400RT, SLAA12-44C/FR, SLADC12-40C, SLR50.
Replaces Group 21R Batteries: CT1250, SLR50, MB86-50, MR86-50.
Important: Always confirm your battery's dimensions, terminal configuration, and specifications before purchase to ensure proper fit and performance.
