VMAX SLR85 Group 24 AGM Deep Cycle Battery – 85Ah / 560 CCA

VMAX

$259.99
SKU:
SLR85
Shipping:
Free Shipping
Voltage:
12V
Type:
AGM
Capacity:
85Ah
Group Size:
24
Terminals:
M8 Inserts
Polarity:
+ Left / - Right
Deep Cycle:
Yes
Dual Purpose:
No
Length:
10.0" - 10.9"
Width:
6.5" - 6.9"
Height:
8.0" - 8.4"
Weight:
55 lbs
Capacity Group:
50 - 100Ah
In Stock
Adding to cart… The item has been added

Product Description

Group 24 AGM Battery

The VMAX SLR85 12V deep cycle battery delivers true AGM performance with an 85Ah capacity in a compact Group 24 case. It’s built for use in RV's, and off-grid energy storage applications that need lasting, steady power for extended periods of time. Engineered using VMAX’s military-grade AGM construction, the SLR85 features thick internal plates, tightly packed separators, and a sealed, maintenance-free design. The result is excellent durability that holds up in the toughest environments.

Features & Benefits

  • 85Ah Deep-Cycle Capacity – Designed for frequent deep discharges without loss of capacity.
  • AGM Construction – Heavy-duty plates with Absorbed Glass Mat separators for extreme durability.
  • Vibration Resistance – Rugged construction that's ideal for RV, marine, and mobile environments.
  • Low Self-Discharge – Maintains a charge longer between uses than conventional flooded batteries.
  • Temperature Tolerant – Dependable power in both high and very low temperatures.
  • Group 24 – Replacement or upgrade for many RV, marine, and off-grid applications.
  • M8 Insert Terminals – Includes new hardware for quick installation and secure connections.
  • Left-Positive Polarity – Verify your current battery's terminal locations before purchase.
  • Built for Commercial Use – VMAX takes pride in building Tough Batteries for Tough Applications.

VMAX SLR Series AGM Batteries

VMAX SLR Series AGM batteries batteries designed to deliver dependable deep-cycle power, day in and day out. Constructed with military-grade lead plates and sealed AGM technology, these batteries deliver consistent performance with zero maintenance and extremely low self-discharge. They’re engineered to handle deep cycling, long standby periods, and heavy vibrations—making them ideal for solar systems, RV's, marine applications, and backup power. Available in capacities from 50Ah to 200Ah, the SLR Series scales easily to match your power requirements without compromise. Whether you’re running off-grid or preparing for outages, VMAX SLR batteries hold their charge, cycle cleanly, and are built to perform—year after year.

Specifications

SLR85

VMAX SLR85 Specifications

12 Volt Group 24 Deep Cycle AGM Battery

  • Nominal Voltage 12V
  • Capacity 85Ah
  • Group Size 24
  • Type Deep-Cycle AGM
View additional specificationsHide additional specifications
Electrical
Nominal Voltage 12 Volts
Capacity 85Ah
Type Deep-Cycle AGM
Cold
Cranking Amps
560 Amps
Marine
Cranking Amps
700 Amps
Dimensions & Fitment
Group Size 24
Length 10.20" (259 mm)
Width 6.60" (168 mm)
Height 8.20" (208 mm)
8.50" (216 mm)
w/terminals
Terminals M8 Inserts
(hardware included)
Polarity + Left / - Right
Weight 55.0 lbs (24.9 kg)
Charging & Warranty
Charging Current 5 - 25 Amps
Charging Voltage 14.4V - 14.9V
Float Voltage 13.5V - 13.8V
Warranty 1 Year

Charging Note: Use a 12V AGM-compatible charger at 14.4V–14.9V (float 13.5V–13.8V). Do not use flooded-battery charge profiles on this battery.

VMAX SLR85 Datasheet
Cross-Reference

VMAX SLR85 Battery Cross-Reference

View DetailsHide Details

Group 24 Batteries w/Studs or Insert Terminals: 24DC-1, 24DC-2, 24M-AGM-MT, 24M5, 24TMX-WNT, 70124, 8A24M, 8G24M, 8G24SS, CB12750-IT, CB12850-IT, CBEV-24-M8, CT2000, DURA12-80C/FR, ES75-12, LFP1280A (AGM), LFP1280D (AGM), M24-3, M75-12 SLD M, MB107-85, MR107-85, PDC-12800 M6, PS-12750 M6, SLA12-80P, SLI24MAGMDC, SLR85, UB12750, US 24DC XC2.



Group 24 Batteries w/Nut & Bolt Terminals: 24TMX-UT, 45821, 8A27-T881, CB12750-NB, CBEV-24-NB, DC12-80P, DCM0012-80, DURDC12-80P, ES12-80P, GP12800P, LC-XD1280P, LFP1280D (AGM), ML80-12P, NP80-12P, PDC-12800 U, PE12V80P, PK12800P, PS-12750 U, SCP12750 NB, SP12-75, UB12750, UB12800P, US 24DC XC2, WKDC12-80P.

Important: Always confirm your battery's dimensions, terminal configuration, and specifications before purchase to ensure proper fit and performance.

CHARGERS

Recommended Chargers for the SLR85

View DetailsHide Details
Compare

Group 24 Batteries

View DetailsHide Details
Applications

Group 24 Applications

View DetailsHide Details
Marine Electronics & House Battery Banks
RV Trailer & Motorhome House Power
Solar & Off-Grid Energy Storage

Warranty Information

1 Year Warranty
